High Voltage DC Miniature Circuit Breaker

SYB5-40P Altus Voltage DC Circuitus Miniaturae Breaker, suppletus a fabrica Sinensis Zhejiang Soutya Novae Energy LLC, 1 500 V DC praesidium praebet.
Key Features
• Facultas summus intentionis: polus unius 500 V DC, usque ad 1,500 V chordae DC-pauciores, costae inferiores.
• Non polarized tutela bidirectionalis celerioris, institutionis facilioris.
• Geminus-confractus contactus cum extra-wide contactum gap pro superiori salute.
• Specimen pro junctura DC scriniorum in systematibus photovoltaicis.

Mitte Inquisitionem

depictio producti

SGB5-40P High Voltage DC Miniature Circuit Breaker supplied by China opificem Zhejiang Soutya New Energy LLC, est 1500 V DC, bidirectional et non-polarizatae minimae rupturae cum 1.5 kA fractionis, specimen pro PV, BESS . et in patina ev-sidii.

Proprium

parvarum grids.
Non-polaris, tutela bidirectionalis;
Onerare tutelam;
Arcus brevis;
Brevis circuitus munitur;
Maximum frangendi facultatem;

Testimonia: CB , CE, TUV , UKCA

Application missiones

SGB5-40P alta intentione DC minimae ambitus ruptor spatii salutaris liberat; tutum, bidirectionale praesidium pro 1 500 V DC systemata renovatio-energiae-PV. repono, EV phiala et DC

1. PV DC iuncturae scriniorum

- 1500 V DC rating chordas longiores permittit, numerum secans pixides junctura; bidirectional praesidio ansas vicissim nocturno tempore excursus.

2. Commercial / residentialibus altilium quatit

- Non polarized wiring simplifies paralleling vel permutando altilium Moduli; sceleste-magneticum iter cito segregat crimen / delicta dimittunt.

3. 150 kW+ DC statio jejunii

- 18 mm-latis DIN-rail designaribus cubiculis compactis; 1.5 kA frangendi capacitatem firmat dc bus internis.

4. DC micro-grids & data-media DC distributionis

— Protegit 750 V / 1 000 V / 1 D V DC gyros ramus ; B, C vel D curvae variae onus perfiles aequant.

5. Summus altitudo vel velit distribui PV

- Operatur ab -30 ° C ad LXX ° C sine derating usque ad II 000 m educere, congruere ambitus asperos.

Technical Parameter

Exemplar		SGB5-40P
Pole		1P	2P	3P	4P
Rated Opus intentione Ue		500VDC	1000VDC	1500VDC	1500VDC

Maximum frame current		40A
Rated Current In		6A, 10A, 16A, 20A, 25A, 32A, 40A
Rated Insulation intentione Ui		1000VDC		1500VDC
Ratum impetum sustinere voltage Uimp		8kV

Labi characteres		B/C/D
Genus supplantando		Scelerisque magnetic
Operational Breaking Capacity Ics		1.5kA(DC)

Ultima solveret facultatem lcu		1.5kA(DC)
Vita electrica
Mediocris valorem re		Mediocris 1000 temporibus
Standard certum valorem		300Times
Mechanica Vita
Mediocris valorem re		≥15000Times
Standard certum valorem		9700Times
Genus Overvoltage		Ⅲ
Pollutio gradus		3
Praesidium Level		IP40: Termina IP20
De humore et calore resistentiae		Category2
Relativum Umor		≤95%
Vibratio Resistentia		Secundum IEC60068-2-6
Mechanica Impact resistentia Morbi		Secundum IEC60068-2-27

Wiring Capacitas		2.5~35mm²
Wiring Torque		3.0Nm
Ambiens Temperature operating		-30℃~+70℃
Repono Ambient Temperature		-40℃~+85℃
Ratio institutionem		DIN35
altitudo		≤2000m
Pondus		0.13kg/Pole
Dimension	Longitudo	108mm

	Latitudo	18mm	36mm	54mm	72mm
	Altitudo	Max 78mm
sarcina	Pcs/Box	12	6	4	3

	Box/Carton	10
	Lobortis / Pallet	80
Repono		Productum in horreis bene ventilatis conditum est humiditas relativa non excedens 80%, et temperatura ambiens debet esse inter -40℃ et + 80℃.Additionally, nihil debet esse acidici, alcalini, vel vapores mordaces praesentes.

Aspectus et instruitur Dimensiones

High Voltage DC Miniature Circuit Breaker

DC Wiring Diagram

High Voltage DC Miniature Circuit Breaker

Derating Factor

Temperature Derating Factor Table

Temperature	-30℃	-25℃	-20℃	-15℃	-10℃	-5℃	0℃	5℃	10℃	15℃
Rated Operating Current Coefficiens	1.279	1.261	0.242	1.223	0.204	1.182	1.161	1.143	1.127	1.103


Temperature	20℃	25℃	30℃	40℃	45℃	50℃	55°C	60℃	65°C	70℃
Rated Operating Current Coefficiens	1.079	1.063	1.047	1	0.984	0.968	0.952	0.922	0.904	0.891

Altitude Derating Factor Table

Altitude /m*	2000	3000	4000	5000
Rated opus Current Coefficiente	1	0.96	0.91	0.86
Rated intentione Coefficiens working	1	1	1	1
Rated Power Frequency resistendi intentione Coefficientis	1	0.9	0.82	0.71
Rated Impetus resistendi intentione Coefficient	1	0.9	0.82	0.71
Rated Low brevis circuitu Segmentum Capacitas et Electrical Vita Coefficiens	1	0.82	0.7	0.6
	1	0.82	0.7	0.6

Factor mensa pro parte institutionem de MCBS dera- by-side

No.of MCB	1	2~3	4~5	6~8	9~10
In≤25A Coefficiens	1	0.96	0.9	0.8	0.7
32A≤In≤63A Coefficiens	1	0.92	0.8	0.7	0.6

Accessorium

Auxiliaris MX fabrica release
Rated Control Voltage Us	DC:24~48V AC:110~230V
Maxime Tripping Tempus	<10ms
Coil Resistentia	5Ω
Terminus current	≥1.6A
Mechanica Vita	10000times
Vita electrica	4000times
Wiring torque	0.8N ·m
Wiring facultatem	1.0mm²Hard filum
	1.0mm Soft filum cum termino lugs
Temperature Range operating	-30℃~+70℃


Environmental conditionibus	Nullae sint substantiae ancipites explosivae, nec noxiae gasorum vel PROLIXUS pulvis qui exedunt vel damnum velit
Conventus positione	Sinistra parte ambitus praevaricator

Institutionem condiciones	DIN35mm vexillum clausurae

Contactus auxiliaris OF
Contactum solveret facultatem	AC13:le=3A;Ue=250V
	AC15:le=2A;Ue=250V
	DC12:le=0.5A;Ue=110V
Minimum Operating intentione	5V


Minimum Operating Current	10mA


Rated Insulation Voltage	500V
Rated breve spatium current Ik	1000A
Constat calefacere current Ith	4A
Mechanica Vita	10000times
Vita electrica	4000times
Wiring torque	0.8N ·m
Wiring facultatem	1.0mm²
Numerus contactus	I normaliter aperta, I Northmanni clausit

Temperature Range operating	-30℃~+70℃
Environmental conditionibus	Nullae sint substantiae ancipites explosivae, nec noxiae gasorum vel PROLIXUS pulvis qui exedunt vel damnum velit

Conventus positione	Sinistra parte ambitus praevaricator

Institutionem condiciones	DIN 35mm vexillum rail ascendens
